DMX protocol
Mode/Total channels
1
/35
1
Pan
0 - 255 Pan movement by 540° (128=default) proportional
2
Pan Fine
0 - 255 Fine control of pan movement (0=default) proportional
3
Tilt
0 - 255 Tilt movement by 270° (128=default) proportional
4
Tilt fine
0 - 255 Fine control of tilt movement (0=default) proportional
5
Pan/Tilt speed , Pan/Tilt time
0 Standard mode (0=default) step
1 Max. Speed Mode step
Pan/Tilt speed mode
2 - 255 Speed from max. to min. proportional
Pan/Tilt time mode
2 - 255 Time from 0.2 s to 25.5 sec. proportional
6
Power/Special functions
0 - 9 Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe”
channel 33 must be at range: 0-31 DMX). Corresponding menu
items are temporarily overriden.
10-14
DMX input: Wired DMX *
step
15-19
DMX input: Wireless DMX *
step
* function is active only 10 seconds after switching the fixture on
20-24
Graphic display: On
step
25-29
Graphic display: Off
step
30-31
Quiet mode: Fans On at blackout
step
32-33
Quiet mode: Fans Off at blackout
step
34-35
Dimmer curve: Super Square Law
step
36-39
Reserved
40-44 Pan/Tilt mode: Speed step
45-49 Pan/Tilt mode: Time step
50-54 Blackout while pan/tilt moving: On step
55-59 Blackout while pan/tilt moving: Off step
60-64 Blackout while gobo wheel moving: On step
65-69 Blackout while gobo wheel moving: Off step
70-74 Blackout while colour wheel moving: On step
75-79 Blackout while colour wheel moving: Off step
80-84
Fans mode: Auto
step
85-89
Fans mode: High
step
90-99
Reserved
100-104
Focus Tracking: On
step
105-109
Focus Tracking: Off
step
110-114
Dimmer curve: Square law
step
115-119
Dimmer curve: Linear
step
120-124 Parking position: On step
125-129 Parking position: Off step
Robin Painte Spot - DMX protocol
Version 1.2
DMX
Value
Function
Type of
control
Page 1
