DMX protocol
Mode/Total channels
DMX
Value
Function
Type of
control
To activate following functions, stop in DMX value for at least 3 seconds.
130 - 139 Total fixture reset (without pan/tilt) step
140 - 149 Pan and Tilt reset step
150 - 159 Colour system reset step
160 - 169 Gobo wheels reset step
170 - 174 Pan reset step
175 - 179 Tilt reset step
180 - 189 Zoom/focus/frost/prism reset step
190 - 199 Iris reset step
200 - 209 Total fixture reset (including pan/tilt) step
210 - 218 Reserved
The following three commands define transition from gobo
rotation to gobo indexing:
219 - 220 Gobo indexing: Maximum speed and shortcut step
221 - 222 Gobo indexing: Follow speed and direction step
223 - 224 Gobo indexing: Maximum speed and follow direction step
The following RoboSpot related commands are only applicable when the RoboSpot
is connected:
225 - 229 RoboSpot enabled step
230 - 234 RoboSpot disabled - except handle faders and pan/tilt step
235 - 239 RoboSpot fully disabled step
240 Disabled "Quiet mode" step
241 - 255 Quiet mode - fan noise control from min. to max. proportional
7
Factory display menu setting: 600Hz
Select PWM output frequency of LEDs. Selected PWM frequency can be
fine adjusted in 127 steps up/down around selected PWM frequency on
the channel below. Corresponding menu item is temporarily overridden.
0-4
PWM frequency from Display menu (fixture utilizes PWM
step
frequency set in the display menu item Frequency Setup).
5-9 300 Hz step
10-14 600 Hz (10=default) step
15-19 1200 Hz step
20-24 2400 Hz step
25-29 High step
30-255
Reserved (fixture utilizes PWM frequency set in the display menu item
Frequency Setup).
8
LED frequency fine adjusting
Factory display menu setting: 600Hz
Select desired PWM output frequency of LEDs on the channel above.
0-1 Selected LED Frequency step
2 LED Frequency (step -126) step
3 LED Frequency (step -125) step
4 LED Frequency (step -124) step
:
125 LED Frequency (step -3) step
126 LED Frequency (step -2) step
127 LED Frequency (step -1) step
