DMX protocol
Mode/Total channels
DMX
Value
Function
Type of
control
128
Selected LED Frequency (128=default)
step
129 LED Frequency (step +1) step
130 LED Frequency (step +2) step
131 LED Frequency (step +3) step
:
252 LED Frequency (step +124) step
253 LED Frequency (step +125) step
254 LED Frequency (step +126) step
255 Selected LED Frequency step
9 Max. light intensity indication and setting
0-10 No function (0=default)
11-20 Indication of drop of max. light intensity step
A drop of max. light intensity of the fixture (compared to its
original intensity) is indicated by a corresponding colour output:
0-5%, (WHITE /new LED module/)
6-10% (RED)
11-15% (GREEN)
16-20% (BLUE )
21-25% (CYAN )
26-30% (MAGENTA)
31-35% (YELLOW)
36-40% (ORANGE)
Pan/tilt is set at 128 DMX (50%), Dimmer is open at 255 DMX
(100%).
To set a drop of max. light intensity (compared to original light
intensity), stay at DMX value for at least 3 sec. and shutter must
be closed at least 3 sec. (Channel 33 „Shutter/ Strobe” must be at
range: 0-31 DMX). Corresponding menu items are permanently
overwritten.
21-30 Set drop by 6-10% (RED) step
31-40 Set drop by 11-15% (GREEN) step
41-50 Drop by 16-20% (BLUE) step
51-60 Set drop by 21-25% (CYAN) step
61-70 Set drop by 26-30% (MAGENTA) step
71-80 Set drop by 31-35% (YELLOW) step
81-90 Set drop by 36-40% (ORANGE) step
91-100 Original intensity (WHITE) step
101-255 Reserved
10
Continual positioning
0 Open/white proportional
12 Deep red proportional
25 Deep blue proportional
39 Light green proportional
51 Lavender proportional
64 Orange proportional
77 Multicolor proportional
90 Filter CRI 90 proportional
Page 3
