DMX protocol
Mode/Total channels
1
/35
DMX
Value
Function
Type of
control
103 CTO 3200K proportional
115 Congo blue proportional
128-129 White step
Positioning
130-136 Deep red step
137-142 Deep blue step
143-149 Light green step
150-155 Lavender step
156-162 Orange step
163-168 Multicolor step
169-175 Filter CRI 90 step
176-182 CTO 3200K step
183-189 Congo blue step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249 Random colour selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random colour selection from fast to slow proportional
11
Colour wheel - fine positioning
0 - 255 Fine positioning (0=default) proportional
12
Cyan
0 - 255 Cyan from min. saturation --> full cyan (0=default) proportional
13
Magenta
0 - 255 Magenta from min. saturation --> full magenta (0=default) proportional
14
Yellow
0 - 255 Yellow from min. saturation --> full yellow (0=default) proportional
15
Virtual CTO
0-255 Colour temperature change from 6700K --> 2700K (0=default) proportional
16 Green correction
0 Uncorrected white step
1-127 Minus green --> uncorrected white proportional
128 Uncorrected white (128=default) step
129-255 Uncorrected white --> Plus green proportional
17
Virtual colour wheel
0 No function (0=default) step
1-2
Filter 4 (Medium Bastard Amber)
step
3-4
Filter 10 (Medium Yellow)
step
5-6
Filter 19 (Fire)
step
7-8
Filter 26 (Bright Red)
step
9-10
Filter 58 (Lavender)
step
11-12
Filter 68 (Sky Blue)
step
13-14
Filter 71 (Tokyo Blue)
step
15-16
Filter 79 (Just Blue)
step
17-18
Filter 88 (Lime Green)
step
19-20
Filter 90 (Dark Yellow Green)
step
21-22
Filter 100 (Spring Yellow)
step
23-24
Filter 101 (Yellow)
step
