DMX protocol
Mode/Total channels
DMX
Value
Function
Type of
control
121-122
Filter 285 (Three Quarter C.T. Orange)
step
123-124
Filter 352 (Glacier Blue)
step
125-126
Filter 353 (Lighter Blue)
step
127-128
Filter 715 (Cabana Blue)
step
129-130
Filter 778 (Millennium Gold)
step
131-132
Filter 793 (Vanity Fair)
step
133-255
Reserved
18
CMY and Colour wheel time
0 Function is off (0=default) step
1 - 255 Time of CMY and Colour wheel movement (0.1sec-->25.5sec.) proportional
19
Zoom/Focus/Frost/Iris/Prism time
0 Function is off (0=default) step
1 - 255
Time of zoom, focus, iris and frost movement (0.1 sec-->25.5 sec.)
proportional
1-50
Time of prism movement (0.1 sec-->5 sec.)
proportional
20
0-8 Open/hole step
Positioning
9-17 Gobo 1 step
18-26 Gobo 2 step
27-35 Gobo 3 step
36-44 Gobo 4 step
45-53 Gobo 5 step
54-62 Gobo 6 step
63-71 Gobo 7 step
72-80 Gobo 8 step
81-91 Gobo 9 step
Shaking gobos from slow to fast
92-103 Gobo 1 proportional
104-115 Gobo 2 proportional
116-127 Gobo 3 proportional
128-139 Gobo 4 proportional
140-151 Gobo 5 proportional
152-163 Gobo 6 proportional
164-175 Gobo 7 proportional
176-187 Gobo 8 proportional
188-199 Gobo 9 proportional
200-201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
21
Index - set indexing on channel 22
0-9 Open/Hole (default) step
10-13 Gobo 1 step
14-17 Gobo 2 step
