DMX protocol
Mode/Total channels
1
/35
DMX
Value
Function
Type of
control
18-21 Gobo 3 step
22-25 Gobo 4 step
26-29 Gobo 5 step
30-33 Gobo 6 step
34-37 Gobo 7 step
38-41 Gobo 8 step
Rotation - set rotation on channel 22
42-45 Gobo 1 step
46-49 Gobo 2 step
50-53 Gobo 3 step
54-57 Gobo 4 step
58-61 Gobo 5 step
62-65 Gobo 6 step
66-69 Gobo 7 step
70-73 Gobo 8 step
Shaking gobos from slow to fast
Index - set indexing on channel 21
74-81 Gobo 1 proportional
82-89 Gobo 2 proportional
90-97 Gobo 3 proportional
98-105 Gobo 4 proportional
106-113 Gobo 5 proportional
114-121 Gobo 6 proportional
122-129 Gobo 7 proportional
130-137 Gobo 8 proportional
Shaking gobos from slow to fast
Rotation - set rotation on channel 22
138-145 Gobo 1 proportional
146-153 Gobo 2 proportional
154-161 Gobo 3 proportional
162-169 Gobo 4 proportional
170-177 Gobo 5 proportional
178-185 Gobo 6 proportional
186-192 Gobo 7 proportional
193-199 Gobo 8 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
22
Rot. Gobo indexing/rotation
Gobo indexing - set position on channel 21
0 - 255 Gobo indexing (128=default) proportional
Gobo rotation - set position on channel 21
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
