DMX protocol
Mode/Total channels
DMX
Value
Function
Type of
control
128 No rotation (128=default) step
129 - 255 Backwards gobo rotation from slow to fast proportional
23
Rot. Gobo indexing/rotation - fine
0-255 Fine indexing/rotation (0=default) proportional
24
0 - 19 Open position/hole (0=default) step
20 - 73 Prism indexing step
74-127 Prism rotation step
Prism/gobo macros
The following channels are blocked: Rotating gobo wheel, Rot.
Gobo indexing and rotation, Rot. Gobo wheel fine rotation
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175 Macro 6 step
176 - 183 Macro 7 step
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231 Macro 13 step
232 - 239 Macro 14 step
240 - 247 Macro 15 step
248 - 255 Macro 16 step
25
Prism indexing - set position on channel 24
0 - 255 Prism 1 indexing proportional
Prism rotation - set position on channel 24
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards prism rotation from slow to fast proportional
26
0 Open (0=default) step
1 - 179 Frost from 0% to 100% proportional
180 - 189 100% frost step
190 - 211 Pulse closing from slow to fast proportional
212 - 233 Pulse opening from fast to slow proportional
234 - 255 Ramping from fast to slow proportional
27
0 Open (0=default) step
1 - 179 From max. diameter to min. diameter proportional
180 - 191 Closed step
Pulse effects with Iris blackout
192 -219 Pulse opening from slow to fast proportional
Page 8
