Fr. Shutter 4 Move channel 80 channel 73 channel 81 channel 74
Fr. Shutter 4 swiveling channel 81 channel 74 channel 82 channel 75
Calibrate Fr. Hysteresis
Framing Lamella 1 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 2 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 3 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 4 - a framing lamella 1 reverse movement (value range: 0-8)
The value set for every framing lamella gives a value at which the lamella reacts to its reverse
movement promptly (without movement hysteresis).
Calibrate Pan/Tilt EMS - This menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Load Default Calibrations - The item loads default (factory) calibration values.
Rotating Gobos Change - This menu makes changing of rotating gobos in the xture easier.
Gobo Carousel 1 - The menu allows movement of rotating gobos to the positions suitable for their changing.
G1-Mg - a movement of the gobo 1 (gobo holder with magnet) to the changing position.
G2 - a movement of the gobo 2 to the changing position.
:
G7 - a movement of the gobo 7 to the changing position.
Gobo Oset -a gobo oset setting. The function allows ne swiveling of the gobo holder. The set value
is valid for all gobos on the gobo carousel.
LEDs Measure - This menu item runs a procedure which measures a light intensity of the LEDs module installed
in the xture. This procedure takes about 1 minute (message " LEDs Module Measurement" is displayed on
the screen"). During the procedure the xture does not receive DMX signal, pan/tilt go to 128 DMX, a shutter
is open and a dimmer is set at max. light intensity (255 DMX). All eects are taken out from the light beam.
The measured light intensity is recorded in the item Intensity in the menu LED Module Info:
Tab Information --> Actual Module Info --> Intensity
Tab Information --> Intensity History --> Intensity
The light intensity in the menu item Intensity is displayed in percentages in relation to the initial intensity of the
new LEDs module (initial intensity=100%).
The LEDs Measure procedure should be run after every change of the LED light source.
Note: The xture has to be connected to mains in order to run LEDs Measure procedure.
Update software -
The menu item allows you to update software in the xture.
The following items are required in order to update software:
- PC running Windows or Linux or macOS
- DSU le
- Flash cable RS232/DMX, P/N13050624 (if you want to use a serial port of PC)
- Robe Universal Interface or Robe Universal interface WTX (if you want to use an USB port of PC)
After the software updating the xture will be set to default values.
To update software in the xture:
1. DSU le is available from Robe web site at WWW.robe.cz.
File with extension zip is intended for Windows (used and tested from XP to W10 on 32/64bit systems).
File with extension tbz is intended for Linux (used and tested on Debian and Ubuntu 32/64bit).
File with extension dmg is intended for
macOS (used and tested on OSX up to Sierra) XQuartz required,
install it from https://www.xquartz.org/
Save the download le to a folder on your computer.
In case that you use windows, extract les in the zip le (e.g. DSU_RobinEsprite_18100828.zip)
2. Disconnect the xture from DMX controller.
3. If you use the ash cable RS232/DMX, connect a serial port of your computer with DMX input of the xture
by means of the cable.
If you use the Robe Universal Interface, connect a USB port of your computer with the Robe Universal Interface
by means of the USB cable and DMX input of the xture with the DMX output of the Robe Universal Interface
via a DMX cable.
4. Switch the xture to the update mode (tab "Service" --> Update Software).
Note: If you do not want to continue in the software update, you have to switch o and on the xture
