DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
86 Green proportional
107 Congo blue proportional
128-129 Open/White step
Positioning
130-141 Deep red step
142-153 Deep blue step
154-165 Orange step
166-177 Green step
178-189 Congo blue step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249 Random colour selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random colour selection from fast to slow proportional
11 * 11 *
Colour wheel 1 - fine positioning
0 - 255 Fine positioning (0=default) proportional
12 11 12 11
Colour wheel 2
Continual positioning
0 Open/white (0=default) proportional
21 Multicolour proportional
43 Laser green proportional
64 Lavender proportional
86 Filter CRI 80 proportional
107 Filter CRI 90 proportional
128-129 Open/White step
Positioning
130-141 Multicolour step
142-153 Laser green step
154-165 Lavender step
166-177 Filter CRI 80 step
178-189 Filter CRI 90 step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249 Random colour selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random colour selection from fast to slow proportional
13 * 13 *
Colour wheel 2 - fine positioning
0 - 255 Fine positioning (0=default) proportional
14 12 14 12
Cyan
0 - 255 Cyan from min. saturation --> full cyan (0=default) proportional
15 13 15 13
Magenta
0 - 255 Magenta from min. saturation --> full magenta (0=default) proportional
16 14 16 14
Yellow
0 - 255 Yellow from min. saturation --> full yellow (0=default) proportional
17 15 17 15
CTO filter
0 - 255 CTO from 6700K --> 3000K (0=default) proportional
