DMX protocol

1 2 3 4

Mode/channel

DMX

Value

Function

Type of

control

* * 18 16

Green correction

0 Uncorrected white step

1-127 Minus green --> uncorrected white proportional

128 Uncorrected white (128=default) step

129-255 Uncorrected white --> Plus green proportional

18 16 19 17

Virtual colour wheel

0 No function (0=default) step

1-2

Filter 4 (Medium Bastard Amber)

step

3-4

Filter 10 (Medium Yellow)

step

5-6

Filter 19 (Fire)

step

7-8

Filter 26 (Bright Red)

step

9-10

Filter 58 (Lavender)

step

11-12

Filter 68 (Sky Blue)

step

13-14

Filter 71 (Tokyo Blue)

step

15-16

Filter 79 (Just Blue)

step

17-18

Filter 88 (Lime Green)

step

19-20

Filter 90 (Dark Yellow Green)

step

21-22

Filter 100 (Spring Yellow)

step

23-24

Filter 101 (Yellow)

step

25-26

Filter 102 (Light Amber)

step

27-28

Filter 103 (Straw)

step

29-30

Filter 104 (Deep Amber)

step

31-32

Filter 105 (Orange)

step

33-34

Filter 106 (Primary Red)

step

35-36

Filter 111 (Dark Pink)

step

37-38

Filter 115 (Peacock Blue)

step

39-40

Filter 116 (Medium Blue-Green)

step

41-42

Filter 117 (Steel Blue)

step

43-44

Filter 118 (Light Blue)

step

45-46

Filter 119 (Dark Blue)

step

47-48

Filter 120 (Deep Blue)

step

49-50

Filter 121 (Filter Green)

step

51-52

Filter 128 (Bright Pink)

step

53-54

Filter 131 (Marine Blue)

step

55-56

Filter 132 (Medium Blue)

step

57-58

Filter 134 (Golden Amber)

step

59-60

Filter 135 (Deep Golden Amber)

step

61-62

Filter 136 (Pale Lavender)

step

63-64

Filter 137 (Special Lavender)

step

65-66

Filter 138 (Pale Green)

step

67-68

Filter 139 (Primary Green)

step

69-70

Filter 141 (Bright Blue)

step

71-72

Filter 147 (Apricot)

step

73-74

Filter 148 (Bright Rose)

step

75-76

Filter 152 (Pale Gold)

step

77-78

Filter 154 (Pale Rose)

step

79-80

Filter 157 (Pink)

step

81-82

Filter 158 (Deep Orange)

step
