Robe Robin Esprite - Page 67

DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
83-84
Filter 162 (Bastard Amber)
step
85-86
Filter 164 (Flame Red)
step
87-88
Filter 165 (Daylight Blue)
step
89-90
Filter 169 (Lilac Tint)
step
91-92
Filter 170 (Deep Lavender)
step
93-94
Filter 172 (Lagoon Blue)
step
95-96
Filter 179 (Chrome Orange)
step
97-98
Filter 180 (Dark Lavender)
step
99-100
Filter 181 (Congo Blue)
step
101-102
Filter 197 (Alice Blue)
step
103-104
Filter 201 (Full C.T. Blue)
step
105-106
Filter 202 (Half C.T. Blue)
step
107-108
Filter 203 (Quarter C.T. Blue)
step
109-110
Filter 204 (Full C.T. Orange)
step
111-112
Filter 205 (Half C.T. Orange)
step
113-114
Filter 206 (Quarter C.T. Orange)
step
115-116
Filter 247 (Filter Minus Green)
step
117-118
Filter 248 (Half Minus Green)
step
119-120
Filter 281 (Three Quarter C.T. Blue)
step
121-122
Filter 285 (Three Quarter C.T. Orange)
step
123-124
Filter 352 (Glacier Blue)
step
125-126
Filter 353 (Lighter Blue)
step
127-128
Filter 715 (Cabana Blue)
step
129-130
Filter 778 (Millennium Gold)
step
131-132
Filter 793 (Vanity Fair)
step
133-255
Reserved
19 17 20 18
Effects Speed
Speed of CMY&CTO movement and Rot. Gobo/Static Gobo
selection
0-255 Speed of CMY+CTO movement from max. to min. (0=default) proportional
0-255 Speed of Rot. Gobo/Stat. Gobo selection from max. to min. proportional
20 18 21 19
CMY+CTO+Colour wheels time
0 Function is off (0=default) step
1 - 255 Time of CMY, CTO and Colour wheels movement (0.1sec-->25.5sec.) proportional
21 19 22 20
Static gobo wheel/ Framing
shutters/Zoom/Focus/Iris/Frost/Prism time
0 Function is off (0=default) step
1-255 Time of Static gobo movement (0.1 sec-->25.5 sec.) proportional
1 - 255
Time of framing shutters, zoom, focus, iris and frost movement (0.1
sec-->25.5 sec.)
proportional
1-50
Time of prism movement (0.1 sec-->5 sec.)
proportional
22 20 23 21
Effect wheel positioning
0-19 No function (0=default) step
20-127 Proportional indexing (73-center) proportional
128-170 Ramping from open to full position ( max--->min. speed) proportional
171-213 Ramping from open to half position ( max. --->min. speed) proportional
214-255 Ramp. from half position to full position ( max. --->min. speed) proportional
23 21 24 22
Effect wheel rotation
Page 7
