DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
0 No rotation step
1 - 127 Forwards rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards rotation from slow to fast proportional
24 22 25 23
Effect wheel animations
0-7 No animation (0=default)
Note :
Set suitable DMX value at
Focus
channel to get desired
animation. All animations were created at distance of 5 m from screen
with zoom=128 DMX, Focus value is different for each effect (focus value is
stated in parentheses for this distance)
The following channels are blocked: Effect wheel positioning, Effect
wheel rotation,Static gobo wheel. Rotating gobo wheel, Rot. Gobo
indexing and rotation, Rot. Gobo wheel fine rotation.
8-9 Macro 1 (Focus=159) step
10-11 Macro 2 (Focus=144) step
12-13 Macro 3 (Focus=146) step
14-15 Macro 4 (Focus=160) step
16-17 Macro 5 (Focus=181) step
18-19 Macro 6 (Focus=181) step
20-21 Macro 7 (Focus=166) step
22-23 Macro 8 (Focus=142) step
24-25 Macro 9 (Focus=151) step
26-27 Macro 10 (Focus=152) step
28-255 Reserved
25 23 26 24
Static gobo wheel
0-8 Open/hole (0=default) step
9-17 Gobo 1 step
18-26 Gobo 2 step
27-35 Gobo 3 step
36-44 Gobo 4 step
45-53 Gobo 5 step
54-62 Gobo 6 step
63-71 Gobo 7 step
72-80 Gobo 8 step
81-91 Gobo 9 step
Shaking gobos from slow to fast
92-103 Gobo 1 proportional
104-115 Gobo 2 proportional
116-127 Gobo 3 proportional
128-139 Gobo 4 proportional
140-151 Gobo 5 proportional
152-163 Gobo 6 proportional
164-175 Gobo 7 proportional
176-187 Gobo 8 proportional
188-199 Gobo 9 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
