DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
26 24 27 25
Rotating gobo wheel
Index - set indexing on channel 27/25/28/26
0-3 Open/hole (0=default) step
4-7 Gobo 1 step
8-11 Gobo 2 step
12-15 Gobo 3 step
16-19 Gobo 4 step
20-23 Gobo 5 step
24-27 Gobo 6 step
28-31 Gobo 7 step
Rotation - set rotation on channel 27/25/28/26
32-35 Gobo 1 step
36-39 Gobo 2 step
40-43 Gobo 3 step
44-47 Gobo 4 step
48-51 Gobo 5 step
52-55 Gobo 6 step
56-59 Gobo 7 step
Shaking gobos from slow to fast
Index - set indexing on channel 27/25/28/26
60 - 69 Gobo 1 proportional
70 - 79 Gobo 2 proportional
80 - 89 Gobo 3 proportional
90 - 99 Gobo 4 proportional
100 - 109 Gobo 5 proportional
110 - 119 Gobo 6 proportional
120 - 129 Gobo 7 proportional
Shaking gobos from slow to fast
Rotation - set rotation on channel 27/25/28/26
130 - 139 Gobo 1 proportional
140 - 149 Gobo 2 proportional
150 - 159 Gobo 3 proportional
160 - 169 Gobo 4 proportional
170 - 179 Gobo 5 proportional
180 - 189 Gobo 6 proportional
190 - 199 Gobo 7 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
27 25 28 26
Rot. gobo indexing and rotation
Gobo indexing - set position on channel 26/24/27/25
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 26/24/27/25
