DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards gobo rotation from slow to fast proportional
28 * 29 *
Rot. gobo indexing/rotation - fine
0-255 Fine indexing/rotation (0=default) proportional
29 26 30 27
Prism
0 - 19 Open position - hole (0=default) step
20 - 73 Prism indexing step
74-127 Prism rotation step
Prism/gobo macros
The following channels are blocked: Prism, Prism rotation, Static gobo
wheel, Rotating gobo wheel, Rot. Gobo indexing and rotation, Rot. Gobo
wheel fine rotation.
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175 Macro 6 step
176 - 183 Macro 7 step
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231 Macro 13 step
232 - 239 Macro 14 step
240 - 247 Macro 15 step
248 - 255 Macro 16 step
30 27 31 28
Prism indexing/rotation
Prism indexing - set position on channel 29/26/30/27
0 - 255 Prism 1 indexing proportional
Prism rotation - set position on channel 29/26/30/27
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards prism rotation from slow to fast proportional
31 28 32 29
Frost
0 Open (0=default) step
Light Frost
1-50 Light Frost from 0% to 100% proportional
51-53 100% Light Frost step
54-63 Pulse closing from slow to fast proportional
64-73 Pulse opening from fast to slow proportional
74-83 Ramping from fast to slow proportional
84-86 Open step
Medium Frost
