DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
87-136 Medium Frost from 0% to 100% proportional
137-139 100% Medium Frost step
140-149 Pulse closing from slow to fast proportional
150-159 Pulse opening from fast to slow proportional
160-169 Ramping from fast to slow proportional
170-172 Open step
Combined Frost
173-222 Medium Frost from 0% to 100% (Light Frost inserted) proportional
223-225 100% Medium Frost (Light Frost inserted) step
226-235 Pulse closing from slow to fast proportional
236-245 Pulse opening from fast to slow proportional
246-255 Ramping from fast to slow proportional
32 29 33 30
Iris
0 Open (0=default) step
1 - 179 From max. diameter to min. diameter proportional
180 - 191 Closed step
Pulse effects with Iris blackout
192 -219 Pulse opening from slow to fast proportional
220 - 247 Pulse closing from fast to slow proportional
248 - 249 Random pulse opening (fast) step
250 - 251 Random pulse opening (slow) step
252 - 253 Random pulse closing (fast) step
254 - 255 Random pulse closing (slow) step
33 * 34 *
Iris - fine
0 - 255 Fine iris movement (0=default) proportional
34 30 35 31
Zoom
0 - 255 Zoom from max. to min. beam angle (128=default) proportional
35 * 36 *
Zoom - fine
0-255 Fine zooming (0=default) proportional
36 31 37 32
Focus
0 - 255 Continuous adjustment from far to near (128=default) proportional
37 * 38 *
Focus - fine
0- 255 Fine focusing (0=default) proportional
38 32 39 33 Framing shutters module rotation
0-127 Rotation from right (0°) to 60° proportional
128 Centre (128=default) step
129-255 Rotation from 60° to left (120°) proportional
39 33 40 34 Framing shutter 1- movement
0-255 Movement from Outward to Inward (0=default) proportional
40 34 41 35 Framing shutter 1- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
41 35 42 36 Framing shutter 2- movement
0-255 Movement from Outward to Inward (0=default) proportional
42 36 43 37 Framing shutter 2- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
128 0 degrees (128=default) step
