Robomow MC300 Operating Manual

20
4.3.3 Setting a Narrow Pass
A Narrow Pass is dened as a path that connects two zones of the lawn. The path enables Robomow to drive
between the zones while following the wire, but prevents the mower from crossing between them while mowing
the inner area of the zones.
To set up a Narrow Pass follow the instructions given in the gure below:
Sub-Zone
Main-Zone
50cm
50cm
50cm
10cm
10cm
Perimeter Island
30x30cm
Perimeter Island
30x30cm
The above setup allows Robomow to drive along the wire to reach the Sub-Zone. However, while mowing each
zone individually, it will not cross over to the other zone.
A. At the point you want the mower to
start driving towards the Sub-Zone
start to set the Narrow Pass.
B. 50 cm (20 inches) from the Narrow
Pass entry, set a Perimeter Island
(refer to 4.2.4) of 30 cm sides (12
inches) at a distance of 10 cm (4
inches) from the Perimeter Wire.
C. Continue to lay the wire towards the
Sub-Zone and lay another Island with
the same dimensions , 50 cm (20
inches) from the Sub-Zone Perimeter
Wire.
D. After completing the setup of the
wire in the Sub-Zone, make sure
you keep 10 cm (4 inches) between
the wire and the islands on the way
back to the Main Zone.
Main Zone
Sub-Zone
Perimeter Island
30x30 cm
Perimeter Island
30x30 cm

Robomow MC300 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
On/off switch	Yes
Cutting system	-
Recommended lawn area	300 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Battery voltage	26 V
Battery technology	Lithium

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11100 g
