24
4.8. Setup in a Non-Base Zone
A Non-Base Zone is an area of the lawn that is not
connected to a Base Station.
A Perimeter Switch should be installed in these areas.
When necessary, the Perimeter Switch can be easily
moved to other zones.
4.8.1 Determining the Perimeter Switch Location
Consider the following in order to install the Perimeter
Switch at an optimal location:
• The Perimeter Switch is to be installed outside the
perimeter of the Non-Base Zone.
• Select a dry and sheltered location.
• The Perimeter Switch is to be mounted vertically.
• The Perimeter Switch is supplied with an indoor
power supply. Choose a location close to a regular
power outlet (230V / 120V).
Note – a rechargeable battery for the Perimeter Switch is
available as an accessory (See Chapter 12 – Robomow
Accessories).
4.8.2 Perimeter Switch placing options
• The Perimeter Switch connector is easily connected and
disconnected. It allows for quickly switching from one zone to
another.
• You may use the large stake, attached to the back of the
Perimeter Switch, to easily insert it in and out of the ground.
• You may mount the Perimeter Switch on a vertical surface,
such as a wall or deck railing. Use the three marks on the back
of the Perimeter Switch cover.
4.8.3 Laying out the Perimeter Wire
The perimeter wire setup in a Base and Non-Base Zone are the
same, except for the starting point:
• The Perimeter Switch is placed out of the area (at least
1 meter from the lawn).
• Start lay the Perimeter Wire from the Perimeter Switch location.
Wires leading from the
lawn to the Perimeter
Switch are adjacent and
touching.
The Perimeter Switch
MUST be Mounted
vertically in order to
maintain its’ water
resistance
Min. 1m (3ft)
To Next Page
