Robomow MC300 Operating Manual

46
11.6 Splicing the Perimeter Wire
If the Perimeter Wire needs to be spliced, use the connectors
supplied in the Robomow box. It is waterproof and gives a reliable
electrical connection.
IMPORTANT! Before slicing the Primeter Wire, disconnect the
Power Box from the power outlet.
1. Strip 1 cm (0.5 inch) of each wire end together and twist the
stripped ends using pliers.
2. Insert the twisted wires into the splicing connector.
3. Screw the wire connector on the twisted wires. Make sure it
is tightly secured.
IMPORTANT! Neither twisted cables, nor a screw terminal
insulated with insulation tape are a satisfactory splice. Soil
moisture will cause such conductors to oxidize and will later lead
to a broken circuit.
11.7 Maintenance of the Base Station Area
• Keep the Base Station entrance and area clean of leaves,
sticks, twigs or any other debris that usually accumulates
in such areas.
• NEVER spray a water hose directly towards the Base
Station.
• Be careful when trimming around the Base Station with a
powered weed trimmer as damage to the Extension Cable
may occur.
• In the event of damage to any part of the Extension Cable,
stop the use of the mower and the Base Station. Disconnect
the Extension Cable and replace it.
11.8 Lightning storm
Warning! To reduce the risk of damage to components in the
case of a lightning storm, disconnect the Perimeter Wire from the
Base Station /Perimeter Switch and the Power Box 230V/120V
plug from the power outlet.
Wire
Connector

Robomow MC300 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
On/off switch	Yes
Cutting system	-
Recommended lawn area	300 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Battery voltage	26 V
Battery technology	Lithium

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11100 g
