Robomow MC300 Operating Manual

31
6.3 Manual Operation
Manual Operation is used when mowing the lawn at unscheduled times.
To initiate Manual Operation when Robomow is at the Base Station, press one of the buttons (except the STOP
button) to show the display.
If the battery is fully charged and the mowing schedule is set to ‘On’, then the start time of the next operation is
displayed, otherwise the current day and time are displayed.
Once the display is shown, choose the operation mode you want as provided in the table below:
Operation Mode Child Lock is Off Child Lock is On
Mowing with Edge –
Mowing the edge before starting
to mow the inner area.
It is recommended to use this
mode once or twice a week,
depending on how fast the grass
is growing.
Press the ‘Edge before mowing’
(left arrow) button once
Press the ‘Edge before mowing’
(left arrow) button then press OK
Mowing without Edge –
Mowing only the inner area
without the edge.
It is recommended to use this
mode only in the rst operation of
each Mowing Cycle.
Press the ‘Mowing’ (right arrow)
button once
Press the ‘Mowing’ (right arrow)
button then press OK
Note – if a Sub-Zone is dened, then once you choose the Operation Mode, then L1 (Main Zone) will be
displayed. Use the arrow buttons to scroll and choose the required zone to be mowed and press OK.
OK to choose /
approve selecon
Mowing with Edge /
Le arrow
Mowing without Edge /
Right arrow
GO to
Base (Home)
Sengs
Stop (during operaon) /
Back while in the menu
ok
STOP

Robomow MC300 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
On/off switch	Yes
Cutting system	-
Recommended lawn area	300 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Battery voltage	26 V
Battery technology	Lithium

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11100 g
