Robomow MC300 Operating Manual

27
5. Preparing Robomow
Before using Robomow for the rst time, you have to perform some simple preliminary settings.
Once the preparations are complete, your Robomow will be ready to mow your lawn.
5.1 Adjust the Cung Height
Blade Cutting Range: 20 – 60 mm (0.8 – 2.4 inches)
To adjust the cutting height of the blade, do the following:
CAUTION! ALWAYS TURN THE SAFETY SWITCH OFF
BEFORE SERVICING BLADE!
• Lift the front side of the mower.
• Turn the knob while pushing it down.
• To raise the cutting height, turn anticlockwise.
• To lower the cutting height, turn clockwise
• The cutting height is displayed at the side of the mower.
5.2 One-Time Setup (Step by Step)
If the mower is in charging, remove it from the Base Station.
Otherwise press the ‘Settings’ button to wake the mower.
Make sure the Power Box is plugged in.
The mower is now ready to perform the One-Time Setup
process.
5.2.1 Using the Operating Panel
Use the buttons on the Operating Panel as follows:
• Press the ‘Right’ or ‘Left’ arrows until your selection is
displayed.
• Press OK to select the value shown on the display.
• Press ‘Back’ (STOP) to go back or to cancel.
5.2.2 Choose Measurements Units and Formats
Area / Distance Temp. Clock
EU Meter Celsius 24 Hours
US Foot Fahrenheit
12 Hours
(AM / PM)
5.2.3 Set Day and Time
• Scroll to set the Day and press OK to conrm.
• Scroll to set the Time and press OK to conrm.
Cung height adjustment
HIGHLOW
Safety Switch
ok
STOP

Robomow MC300 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
On/off switch	Yes
Cutting system	-
Recommended lawn area	300 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Battery voltage	26 V
Battery technology	Lithium

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11100 g
