Robotiq 3-Finger Adaptive Robot Gripper Instruction Manual
Robotiq inc. © 2008 - 2014 116
S-152
Adapter plate for 56 mm PCD ,
1
eight (8) M5 screws, one (1) 4 mm
M6 dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-152
S-153
Adapter plate for 40 mm PCD , five
1
(5) M6 screws, one (1) 6 mm M6
dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-153
S-155
Adapter plate for 40 mm PCD ,
1
four (4) M6 screws, one (1) 6 mm
M6 dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-155
S-156
Adapter plate for 80 mm PCD , six
1
(6) M8 screws, two (2) 8 mm M6
dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-156
S-157
Adapter plate for 50 mm PCD ,
1
seven (7) M6 screws, one (1) 6 mm
M6 dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-157
S-158
Adapter plate for 50 mm PCD ,
1
four (4) M6 screws.
Meant for use on S-101 Coupling.
AGS-APL-158
S-159
Adapter plate for 100 mm PCD ,
1
ten (10) M8 screws, two (2) 8 mm
M6 dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-159
S-160
Adapter plate for 55 mm PCD ,
1
four (4) M4 screws, two (2) 6 mm
M6 dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-160
S-161 Adapter plate for four (4) M6 screws
on 63 mm PCD , two (2) 6 mm M6
1
dowel pin on 61.4 mm PCD .
1
Meant for use on S-101 Coupling.
AGS-APL-161
S-163 Adapter plate for seven (7) M5
screws on 31.5 mm PCD , one (1)
1
5 mm M6 dowel pin.
Meant for use on S-101 Coupling.
AGS-APL-163
S-164 Adapter plate for eight (8) M5
screws on 31.33 mm PCD
1
, one (1)
5 mm M6 dowel pin.
AGS-APL-164
