RBTNKDOC160609A
SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

● LEDsStatus
o LED1RED:ACPoweron
o LED2RED:Charging
o LED2GREEN:Chargingcompletedorbatterynotconnected
● Temperature
o Operatingtemperature:5ºC~+40ºC
o Storagetemperature:10ºC~+70ºC
Caution:
● Thechargerisdesignedforindooruseonly.
● Thechargershouldbeplacedhorizontallyandoperateinwellventilated
condition,avoidhumidityandkeepitawayfrominflammableexplosivematerial.
● Thealuminumcaseisaheatsink,donotcoverit.
● Donotdisassemblethechargerduetohighvoltageinside.

Figure21–LiFePo4SmartChargerFrontview
 
Figure22–LiFePo4SmartChargerRearview

Ifyouhavetroublechargingbatteriescheckthese:

25

