Robotnik SUMMIT XL - Page 26


RBTNKDOC160609A
SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

ChargerLED1isoff
CheckchargerPowerSwitch
CheckchargerInputFuse
ChargerLED2isgreen
Ifbatteryiscloseto29.2Visalreadycharged
Checkifchargerconnectorisproperlyattached
attherobotbackpanel
CheckchargerOutputFuse
CheckSummitXLFuseF0
Table6–Chargingtroubletips



 
