Lower Leg Seal Service
Soak new foam rings in Maxima PLUSH Dynamic Suspension Lube.Soak new foam rings in Maxima PLUSH Dynamic Suspension Lube.
Install the new foam rings into the lower leg.Install the new foam rings into the lower leg.
Remove the outer wire spring from each new dust wiper seal and set Remove the outer wire spring from each new dust wiper seal and set
them aside.them aside.
Insert the narrow end of a new wiper seal into the recessed end of the Insert the narrow end of a new wiper seal into the recessed end of the
RockShox Dust Seal Installation Tool.RockShox Dust Seal Installation Tool.
38 mm38 mm - ZEB - ZEB
35 mm35 mm - Lyrik and Pike - Lyrik and Pike
Stabilize the lower leg on a bench top. Hold the lower leg steady and Stabilize the lower leg on a bench top. Hold the lower leg steady and
press, or tap with a mallet, the wiper seal into the lower leg until the top press, or tap with a mallet, the wiper seal into the lower leg until the top
of the seal is flush with the top of the lower leg.of the seal is flush with the top of the lower leg.
Repeat on the other side.Repeat on the other side.
NOTICE
Only press, or tap with a mallet, the wiper seal into the lower leg
until it is flush with the top surface of the lower leg. Pressing the
wiper seal below the top surface of the lower leg will compress the
foam ring.
4
Maxima PLUSH Dynamic Suspension
Lube
5
6
RockShox Dust Seal Installation Tool
7
RockShox Dust Seal Installation Tool Mallet
