Test Lockout Compression
200 Hour Service Test Lockout Compression
Use a Schrader valve core tool to rotate the keyed adjuster clockwise Use a Schrader valve core tool to rotate the keyed adjuster clockwise
until it lightly contacts the stop point, to the locked out or firmest until it lightly contacts the stop point, to the locked out or firmest
position.position.
NOTICE
Do not over-rotate the keyed adjuster against the stop point. Over-
rotation, or tightening, against the stop point can damage internal
parts.
Position the rebound damper shaft squarely on a flat surface while Position the rebound damper shaft squarely on a flat surface while
holding the compression circuit closed with the Schrader valve core holding the compression circuit closed with the Schrader valve core
tool.tool.
Push down on the damper assembly to test the bleed.Push down on the damper assembly to test the bleed.
Consistent resistance should be felt with no gaps in movement. If gaps Consistent resistance should be felt with no gaps in movement. If gaps
are felt during compression, repeat the bleed process.are felt during compression, repeat the bleed process.
If the bleed was successful, rotate the compression damper keyed If the bleed was successful, rotate the compression damper keyed
adjuster counter clockwise to the open position, then rotate it one half adjuster counter clockwise to the open position, then rotate it one half
turn clockwise.turn clockwise.
1
Schrader valve core tool
2
Schrader valve core tool Schrader valve core tool
