RockShox PIKE - 200 Hour Service ButterCup Removal - Damper Shaft

43
ButterCup Removal - Damper Shaft
200 Hour Service ButterCup Removal - Damper Shaft
Clamp the lower ButterCup housing into a vise with Reverb Vise Blocks Clamp the lower ButterCup housing into a vise with Reverb Vise Blocks
or RockShox Rear Shock Vise Blocks on the wrench flats, with the or RockShox Rear Shock Vise Blocks on the wrench flats, with the
damper oriented downward.damper oriented downward.
Hold the damper shaft for support and unthread the upper ButterCup Hold the damper shaft for support and unthread the upper ButterCup
housing from the lower housing.housing from the lower housing.
Remove the damper assembly from the lower cup and set it aside.Remove the damper assembly from the lower cup and set it aside.
Remove the lower ButterCup bumper from the lower ButterCup Remove the lower ButterCup bumper from the lower ButterCup
housing and discard it. housing and discard it.
Remove the lower ButterCup housing from the vise. Remove the lower ButterCup housing from the vise.
Do not remove the alignment bolt.Do not remove the alignment bolt.
Remove the lower ButterCup housing from the vise. Clean the lower Remove the lower ButterCup housing from the vise. Clean the lower
ButterCup housing.ButterCup housing.
1
25 mm or adjustable open end wrench
2
3
Pick (non-metallic)
4
