DebonAir+ - Air Spring Travel Change and Bottomless Tokens (optional)
DebonAir+ - Air Spring Travel Change and Bottomless Tokens (optional)
It is optional to change maximum fork travel by replacing the stock air spring shaft assembly with a shorter or longer air spring shaft assembly. If
maximum travel is increased or reduced, use the new complete air spring shaft assembly in the following installation steps. It may also be necessary
to add or remove Bottomless Tokens. Refer to Air Spring Travel Change and Bottomless Tokens for details.
Refer to the RockShox Spare Parts Catalog at www.sram.com/service for available air spring and Bottomless Token kits.
For part ordering information, please contact your local SRAM distributor or dealer.
200 Hour Service Air Spring Service
A ZEB air spring assembly is pictured in this section. Procedures are A ZEB air spring assembly is pictured in this section. Procedures are
the same for ZEB, Lyrik, and Pike air spring assemblies.the same for ZEB, Lyrik, and Pike air spring assemblies.
Remove the air seal head assembly and top out bumper from the air Remove the air seal head assembly and top out bumper from the air
spring shaft.spring shaft.
Discard the seal head assembly.Discard the seal head assembly.
NOTICE
Scratches on the air spring shaft can cause air to leak. If a scratch is
visible the air spring assembly may need to be replaced.
Remove the top out bumper. Remove the top out bumper.
Clean the top out bumper.Clean the top out bumper.
Clean and inspect the air spring shaft for damage.Clean and inspect the air spring shaft for damage.
Lyrik Pike
1
2
Pick (non-metallic)
