Exploded View - 2022 ZEB Ultimate Flight Attendant
Exploded View - 2022 ZEB Ultimate Flight Attendant
Flight Attendant
Control Module
Battery block
Compression damper top cap
Dust wiper seal
Foam ring
Rebound damper piston
Rebound damper seal head
Crush washer
Rebound bottom bolt
Rebound adjuster knob
Steerer tube
Air spring top cap
Air spring piston
Top out cup
Top out bumper
Upper tube
Air spring seal head
Retaining ring
Air spring shaft
Crush washer
Air spring
bottom bolt
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Brake hose guide
Compression damper
ButterCup (air shaft)
Bottomless Token(s) 35 mm grey (optional)
Maxle Stealth
Battery
Bleed port
Sag o-ring
Crown
Air cap
Lower leg arch
ButterCup (damper shaft)
Damper tube
Air seal head spacer
