Damper Service
200 Hour Service Damper Service
Clamp the cartridge tube wrench flats in a vise with flat soft jaw inserts, Clamp the cartridge tube wrench flats in a vise with flat soft jaw inserts,
rebound damper oriented upward.rebound damper oriented upward.
Wrap a shop towel around the cartridge tube to absorb oil.Wrap a shop towel around the cartridge tube to absorb oil.
Unthread and slowly remove the rebound damper and seal head Unthread and slowly remove the rebound damper and seal head
assembly from the cartridge tube.assembly from the cartridge tube.
Remove the seal head from the rebound damper shaft and discard it.Remove the seal head from the rebound damper shaft and discard it.
The solid band glide ring is not removable and only requires cleaning. The solid band glide ring is not removable and only requires cleaning.
Do not remove.Do not remove.
1
Vise and flat soft jaw inserts
2
23 mm
