44
ButterCup Removal - Damper Shaft
Clamp the damper shaft into the 10 mm slot of the RockShox Reverb Clamp the damper shaft into the 10 mm slot of the RockShox Reverb
Vise Blocks or RockShox Rear Shock Vise Blocks with the damper Vise Blocks or RockShox Rear Shock Vise Blocks with the damper
oriented downward.oriented downward.
Clamp the damper shaft only tight enough so it does not spin when the Clamp the damper shaft only tight enough so it does not spin when the
ButterCup shaft end plate is removed.ButterCup shaft end plate is removed.
NOTICE
Scratches on the damper shaft can cause oil to leak. If a scratch is
visible the rebound damper assembly may need to be replaced.
Unthread and remove the ButterCup shaft end plate from the damper Unthread and remove the ButterCup shaft end plate from the damper
shaft.shaft.
Remove the upper ButterCup bumper and discard it.Remove the upper ButterCup bumper and discard it.
Remove the upper ButterCup housing and bushing assembly from the Remove the upper ButterCup housing and bushing assembly from the
damper shaft.damper shaft.
5
T25 RockShox Vise Blocks 10 mm
6
