RockShox PIKE - Damper Service Procedures; 200 Hour Service Flight Attendant Control Module Removal

39
Damper Service
Damper Service
200 Hour Service Flight Attendant Control Module Removal
The compression damper must be in the OPEN position before The compression damper must be in the OPEN position before
removing the Control Module.removing the Control Module.
Press and hold the Menu button until one LED pulses red. Press and hold the Menu button until one LED pulses red.
If necessary, press and release the (If necessary, press and release the (
++
) or () or (
−−
) adjuster button until the ) adjuster button until the
red OPEN LED pulses.red OPEN LED pulses.
Remove the SRAM battery and install the battery block.Remove the SRAM battery and install the battery block.
Install the battery cover on the SRAM battery and set it aside.Install the battery cover on the SRAM battery and set it aside.
OptionalOptional: Insert the SRAM battery onto the battery charger.: Insert the SRAM battery onto the battery charger.
Loosen each Flight Attendant Control Module set screw. Loosen each Flight Attendant Control Module set screw.
Do not remove the set screws.Do not remove the set screws.
1
2
3
2 mm 2 mm
