63
Lower Leg Installation
50/200 Hour Service Lower Leg Installation
Clean the upper tubes.Clean the upper tubes.
Apply grease to the inner surfaces of the dust wiper seals.Apply grease to the inner surfaces of the dust wiper seals.
Install the lower leg assembly onto the upper tubes and slide it just Install the lower leg assembly onto the upper tubes and slide it just
enough to engage the upper bushings with the upper tubes. enough to engage the upper bushings with the upper tubes.
NOTICE
Make sure both wiper seals slide onto the tubes without folding the
outer lip of either seal.
The inside bottom of the lower leg should not contact the air spring The inside bottom of the lower leg should not contact the air spring
and damper shaft ButterCups. A gap between the ButterCups and the and damper shaft ButterCups. A gap between the ButterCups and the
lower leg bolt holes should be visible.lower leg bolt holes should be visible.
1
RockShox Suspension Cleaner
2
SRAM Butter Grease
3
To Next Page
