64
Lower Leg Installation
Position the fork at an angle with the bolt holes oriented upward.Position the fork at an angle with the bolt holes oriented upward.
Inject Maxima PLUSH Dynamic Suspension Lube into each lower leg Inject Maxima PLUSH Dynamic Suspension Lube into each lower leg
through the bottom bolt holes.through the bottom bolt holes.
NOTICE
Do not exceed the recommended oil volume per leg as this can
damage the fork.
Fork Damper Side (mL) Spring Side (mL)
ZEB
30 15Lyrik
Pike
SSlide the lower leg assembly toward the crown until it stops.
The air spring and damper ButterCup shaft ends should be visible he air spring and damper ButterCup shaft ends should be visible
through the bottom bolt holes.through the bottom bolt holes.
Verify each ButterCup shaft end is centered and seated in the lower Verify each ButterCup shaft end is centered and seated in the lower
leg shaft/bolt hole and no gap is visible between the lower leg and leg shaft/bolt hole and no gap is visible between the lower leg and
each threaded shaft end.each threaded shaft end.
Align the ButterCup shaft ends into the bottom bolt holes if needed.Align the ButterCup shaft ends into the bottom bolt holes if needed.
4
Maxima PLUSH Dynamic Suspension Lube See Table
5
Spring side Damper side
To Next Page
