65
Lower Leg Installation
200 Hour Service 200 Hour Service Remove the old crush washers from each bottom Remove the old crush washers from each bottom
bolt.bolt.
Hold the crush washer with needle nose pliers and unthread it from the Hold the crush washer with needle nose pliers and unthread it from the
bolt by turning the bolt counter-clockwise. Discard the crush washers.bolt by turning the bolt counter-clockwise. Discard the crush washers.
Clean the bolts and install new crush washers.Clean the bolts and install new crush washers.
NOTICE
Do not damage the bolt threads.
Do not reuse crush washers or crush washer retainers. Dirty or
damaged crush washers can cause oil to leak from the fork.
Install the solid bottom bolt into the spring side shaft.Install the solid bottom bolt into the spring side shaft.
Install the hollow bolt into the damper side shaft.Install the hollow bolt into the damper side shaft.
Tighten each bolt.Tighten each bolt.
6
5 mm Pick 5 mm Needle nose pliers
7
5 mm Spring side 5 mm 6.8 Nm (60 in-lb)
5 mm Damper side 5 mm 6.8 Nm (60 in-lb)
