RockShox PIKE - Page 49

49
Damper Assembly
Insert the rebound damper piston slowly into the cartridge tube and Insert the rebound damper piston slowly into the cartridge tube and
thread the sealhead into the tube.thread the sealhead into the tube.
Tigthen the seal head.Tigthen the seal head.
Thread the rebound bottom bolt into the shaft 3-4 turns.Thread the rebound bottom bolt into the shaft 3-4 turns.
3
23 mm 5.1 Nm (45 in-lb)
4
