Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 257
Chapter 12 Using microSD Cards
9. Assign the variables to the RCP input and output parameters as follows:
Note: For CfgID input parameter, you can choose a predefined variable by choosing from the
Defined Words in the Connected Components Workbench software. To do so, click the CfgID
input box. From the Variable Selector window that appears, click the Defined Words tab and
choose from the list of defined words. For example, RCP1 that corresponds to RCP1 in your
recipe configuration. See Figure 27
.
Figure 27 - Choose a Predefined Variable
