Chapter 3 Input Module Features
Table 10 - FLEX 5000 Digital Input Module - Fault and Data Status
Data Type Tag Name
(1)
(1) Not all tag names apply to all FLEX 5000 digital input modules.
Triggering Event That Sets the Tag
Fault
ConnectionFaulted
(2)
(2) This tag provides module-wide data and affects all points simultaneously.
The owner-controller loses its connection to the module.
PtxxFault The point data quality is bad.
This tag is used if you select Packed Data in the module definition.
Ptxx.Fault The point data quality is bad.
Status
RunMode The module is in Run Mode.
DiagnosticActive Indicates if any diagnostics are active.
DiagnosticSequenceCount A counter that increments when a diagnostic condition occurs or
goes away. The counter is a rolling counter that skips 0 on rollovers.
PtxxData The point input status is one or zero.
This tag is used if you select Packed Data in the module definition.
Ptxx.Data The point input status is one or zero.
Ptxx.Uncertain The point data can be imperfect.
Uncertain The module is operating outside its designed operating range if
data is under manual or override control.
