Chapter 1
ControlLogix Embedded Edge Compute Module
The ControlLogix® Embedded Edge Compute module is a chassis-based module that can
communicate directly with Logix controllers, and has read and write access to all controller
tags through the backplane and front Ethernet port.
The Embedded Edge Compute module enables FactoryTalk® Optix Studio™, a development
platform for creating human machine interface (HMI) and Internet of Things (IoT) applications.
The Embedded Edge Compute module contains a FactoryTalk® Optix™ XS runtime license with
five tokens, and a FactoryTalk® Remote Access™ Runtime Pro license.
Catalog Number
Explanation
The ControlLogix Compute Embedded Edge module catalog number indicates specific
information about the module. The module uses the format 1756-CMEExyz, where the
following apply:
• 1756 is the Bulletin number.
• CMEE = Embedded Edge Compute Module
• x represents the microSD™ card capacity
• y represents the embedded OS that is installed on the module
• z represents the application that is shipped on the module
Minimum Requirements The module has these minimum requirements:
• ControlLogix Chassis, Series C (Series B chassis function within a derated temperature
range)
• ControlLogix Chassis Power Supply
• FactoryTalk Optix Studio version 1.20 or later
• If you want to use the Studio 5000 Logix Designer® application to configure the module,
you need:
- A ControlLogix 5570 or 5580 controller with firmware revision 28.011 or later.
- Studio 5000 Logix Designer version 28.00.00 or later.
- Add-on Profile for 1756 Embedded Edge Compute version 40.00.45 or later
ControlLogix Embedded Edge Compute Module Catalog Number (1756-CMEE1Y1)
Variable Attribute Possible Value
x microSD card capacity 1 = 32 GB
y Operating system Y = Embedded Yocto Linux OS 64-bit
z Application that is shipped on the module 1 = No application
