8 Rockwell Automation Publication 1756-UM021A-EN-P - September 2023
Chapter 1 ControlLogix Embedded Edge Compute Module
Module Components This table describes the components available on the Embedded Edge Compute module.
Embedded Edge Compute Module Components
Component Description
Linux Yocto 64-bit embedded OS Embedded operating system.
Onboard memory 4 GB - RAM
eMMC memory 20 GB - Mass storage
Four-character display Scrolls information about the module.
Status indicators Shows information about the module status and health.
Reset button Used with the embedded OS to restart the module.
Factory Restore button
The factory restore button:
• Resets all settings.
• Restores the operating system and module firmware
• Removes the FactoryTalk Remote Access identity.
USB 3.0 port Connect USB peripherals.
Two 1 Gb Ethernet ports Used with the Ethernet protocol.
Rotary switches Not functional currently.
microSD Card (1784-MSDHC32)
•32 GB
• One microSD card is included in the product and is considered a part of
the product.
• Declared data retention and Factory Reset times are valid only when
using the microSD card included in the product.
• Rockwell Automation recommends you only replace the microSD card if it
fails.
• Replacing the microSD card for any other reason is not recommended,
and is taken at your own risk.
