152 Rockwell Automation Publication 2198-UM001D-EN-P - May 2014
Chapter 7 Troubleshooting the Kinetix 5500 Drive System
Table 72 - Drive Behavior, NODE FLT Fault Codes
Exception Fault Code Exception Text
Permanent
Magnet Motor
Induction Motor
Fault Action
Best Available
Stopping Action
(applies to major faults)
Ignore
Alarm
Minor Fault
Major Fault
NODE FLT 01 – LATE CTRL UPDATE Control Connection Update Fault X X X Decel/Disable
NODE FLT 02 – PROC WATCHDOG Processor Watchdog Fault X X X Disable/Coast
NODE FLT 03 – HARDWARE Hardware Fault X X X Disable/Coast
NODE FLT 05 – CLOCK SKEW FLT Clock Skew Fault X X X Disable/Coast
NODE FLT 06 – LOST CTRL CONN Lost Controller Connection Fault X X X Decel/Disable
NODE FLT 07 – CLOCK SYNC Clock Sync Fault X X X Disable/Coast
NODE FLT 09 – DUPLICATE IP ADDRESS Duplicate IP Address Fault X X X Disable/Coast
