Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 167
Chapter 10
Kinetix 5500 Safe Torque-off - Integrated Safety
This chapter introduces you to how the integrated safe torque-off feature meets
the requirements of Performance Level e (PLe), Category 3 according to
EN ISO 13849, and SIL CL3 according to IEC 61508, EN 61800-5-2, and
EN 62061.
With integrated safety, the 1756-L7xS GuardLogix safety controller issues the
safe torque-off (STO) command over the EtherNet/IP network and the
2198-Hxxx-ERS2 servo drive executes the STO command.
Certification
The TÃœV Rheinland group has approved the 2198-Hxxx-ERS2 servo drives
with integrated safe torque-off for use in safety-related applications up to PLe,
Category 3 according to EN ISO 13849 and SIL CL3 according to IEC 61508,
EN 61800-5-2, and EN 62061, in which removing the motion producing power
is considered to be the safe state.
Refer to Appendix E on page 229
for these certification documents.
• EC Type - Examination Certificate
• EC Declaration of Conformity
• European Union Directives
Topic Page
Certification 167
Description of Operation 169
Probability of Dangerous Failure Per Hour (PFH) 171
Safe Torque-off Feature 172
Out-of-Box State 172
Understanding Integrated Safety Drive Replacement 174
Replacing an Integrated Safety Drive in a GuardLogix System 175
Motion Direct Commands in Motion Control Systems 181
Safe Torque-off Specifications 187
Safe Torque-off Specifications 187
