Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 227
Induction Motor Support Appendix D
Table 93 - Skip Frequency Examples
Acceleration and deceleration are not affected by the skip frequencies. Normal
accel/decel proceeds through the band.
Skip Band Description Graphic Illustration
The skip frequency has hysteresis so the
output does not toggle between high
and low values. You can program three
distinct bands. If none of the skip bands
touch or overlap, each band has its own
high/low limit.
If the band is outside of the limits, the
skip band is inactive.
Frequency, max
Skip Frequency
Skip Band
0 Hz
400 Hz
Skip Frequency
60 Hz Frequency,
max
Inactive
Skip Band
To Next Page
