Rockwell Automation Publication 2198-UM001D-EN-P - May 2014 45
Chapter 3
Mounting the Kinetix 5500 Drive System
This chapter provides the system installation procedures for mounting your
Kinetix 5500 drives to the system panel.
This procedure assumes you have prepared your panel and understand how to
bond your system. For installation instructions regarding equipment and
accessories not included here, refer to the instructions that came with those
products.
Topic Page
Determining Mounting Order 46
Drilling Hole Patterns 49
Mount Your Kinetix 5500 Drive 56
SHOCK HAZARD: To avoid hazard of electrical shock, perform all mounting and
wiring of the Kinetix 5500 drives prior to applying power. Once power is
applied, connector terminals can have voltage present even when not in use.
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful to
keep metal debris from falling into it. Metal debris or other foreign matter can
become lodged in the circuitry and result in damage to the components.
