Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
D248 7
200 — 248 — 272.1 176.9
13800
—150—186204.1132.7
D302 7
250 — 302 — 331.3 214.7
13800
—200—248272.1176.3
D361 7
300 — 361 — 396.1 256.6
13800
— 250 — 302 331.3 214.7
D415 7
350 — 415 — 455.3 295
18400
— 300 — 361 396.1 256.6
D477 7
400 — 477 — 523.3 340.1
18400
— 300 — 361 396.1 257.5
(1) Drive input type (position 5 of catalog number) = 1 (AC input with precharge, includes DC terminals) or 4 (DC input
with precharge).
Table 9 - PowerFlex 750-Series Drives — Frames 1…7, 480V AC (Continued)
Cat. No.
20F…/
20G…
(1)
Frame
Size
AC Output Rating
HP
AC Output
Rating Amp RMS DC Input Rating
Internal DC Bus
Capacitance (µF)ND HD ND HD Amps kW
