Rockwell Automation PowerFlex 755TM User Manual

68 Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022
Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
Table 10 - PowerFlex 755TM Common Bus Inverters — Frames 8…15, 480V AC
Cat. No.
20G…
(1)
(1) Drive input type (position 5 of catalog number) = D (common bus with DC precharge) or E (common bus without DC precharge).
Frame
Size
AC Output Rating HP AC Output Rating Amp RMS DC Input Rating
Internal DC Bus
Capacitance (µF)ND HD ND HD Amps kW
D302 8
250 — 302 — 333 216.5
9000
—200— 248 274178.1
D361 8
300 — 361 — 399 259.4
9000
— 250 — 302 333 216.5
D430 8
350 — 430 — 475 308.8
9000
—300— 361 399259.4
D505 8
400 — 505 — 558 362.7
9000
—350— 430 475308.8
D545 8
450 — 545 — 602 391.3
15000
— 350 — 454 475 308.8
D617 8
500 — 617 — 681 442.7
15000
—400— 485 535347.8
D710 8
600 — 710 — 784 509.6
15000
— 450 — 545 602 391.3
D740 8
650 — 740 — 817 531.1
15000
—500— 617 681442.7
D800 9
700 — 800 — 883 574
18000
—600— 740 817531.1
D960 9
800 — 960 — 1060 689
18000
— 700 — 800 883 574
D1K0 9
900 — 1045 — 1154 750.1
30000
— 750 — 960 1060 689
D1K1 9
1000 — 1135 — 1253 814.5
30000
— 800 — 1045 1154 750.1
D1K3 9
1100 — 1365 — 1507 979.6
30000
—900— 1135 1253814.5
D1K4 10
1250 — 1420 — 1568 1019.2
45000
— 1000 — 1365 1507 979.6
D1K6 10
1500 — 1655 — 1827 1187.6
45000
— 1100 — 1420 1568 1019.2
D2K0 10
1800 — 2072 — 2288 1487.2
45000
— 1500 — 1655 1827 1187.6
D2K6 11
2400 — 2738 — 3023 1965
60000
— 2000 — 2240 2473 1607.5
D3K4 12
3000 — 3404 — 3758 2442.7
75000
— 2400 — 2980 3290 2138.5
D4K0 13
3600 — 4070 — 4494 2921.1
90000
— 2800 — 3394 3746 2434.9
D5K4 14
4800 — 5402 — 5964 3876.6
120000
— 3700 — 4504 4971 3231.2
D6K7 15
6000 — 6734 — 7435 4832.8
150000
— 4600 — 5615 6197 4028.1
