Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022 69
Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
Table 11 - Kinetix 5700 Modules, 480V AC
(1)
(1) For the Kinetix 5700 single- and dual-axis servo drives, fuse is internal to product and isn’t field replaceable.
Module Cat. No.
Frame Width
(mm)
AC Output ND Continuous
(2)
(2) These attributes apply to each of the axes in the dual-axis inverter modules (2198-Dxxx).
DC Input ND Continuous
Module DC Bus Capacitance (μF)kW Amp RMS Amps kW
2198-D006-ERSx 55 1.7 2.5 2.7 1.8 165
2198-D012-ERSx 55 3.4 5 5.3 2.9 165
2198-D020-ERSx 55 5.5 8 8.5 4.7 330
2198-D032-ERSx 55 8.9 13 13.7 7.6 390
2198-D057-ERSx 85 15.9 26 24.5 13.5 705
2198-S086-ERSx 85 29.7 43 45.7 25.3 560
2198-S130-ERSx 85 44.9 65 69 38.2 840
2198-S160-ERSx 100 60.1 85 92.3 51.2 1120
2198-S263-ERSx 220 90 150 164 78.4 2050
2198-S312-ERSx 220 112 192 207 97.3 2050
2198-CAPMOD-2240 55————2240
2198-DCBUSCOND-RP31255————0
2198-CAPMOD-DCBUS-IO55————0
