Rockwell Automation PowerFlex 755TM User Manual

70 Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022
Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
Table 12 - PowerFlex 755TM Regenerative Bus Supplies — Frames 6…15, 480V AC (696V DC Output)
Cat. No.
20J…
(1)
Frame
Size
DC Output Rating
Internal DC Bus Capacitance (μF) Max External DC Bus Capacitance (μF)
kW
Continuous
AmpsND HD
D125 6
90 — 129
9200 10960
—6999
D156 6
111 — 160
9200 10960
—90129
D186 6
133 — 191
13800 18168
—111160
D248 6
177 — 255
13800 18168
—133191
D302 7
216 — 311
9000 68472
—177255
D361 7
258 — 371
9000 68472
—216311
D430 7
307 — 442
9000 68472
—258371
D505 7
361 — 519
9000 68472
—307442
D617 7
426 — 617
9000 68472
—355514
D302 8
216 — 311
9000 56088
—177255
D361 8
258 — 371
9000 56088
—216311
D430 8
307 — 442
9000 56088
—258371
D505 8
361 — 519
9000 56088
—307442
D545 8
390 — 560
15000 80472
—307442
D617 8
442 — 635
15000 80472
— 347 499
D710 8
508 — 730
15000 80472
— 390 560
D740 8
529 — 761
15000 80472
—442635
D800 9
573 — 823
18000 105840
—529761
D960 9
687 — 987
18000 119600
—573823
D1K0 9
748 — 1075
30000 146112
—687987
D1K1 9
812 — 1167
30000 146112
—7481075
