Rockwell powerflex 700s User Manual

Schematics B-7
Fan Power Supply Connections
X8
X2
3
Fan Frequency Converter
+-
Off
S1-1
Off
S1-2
On
S1-3
Off
S1-4
S1 - Setup Switch
From ASIC
Board X11
M1
Black
Yellow/Green
Blue
Main Fan Left-Side 230V ac 50 Hz
M
Black 6 Black 5 Black 4 Black 3
Black 2 Black 1
X4 X5
2.2
μ
f 10 M
Ω
2.2
μ
f 10 M
Ω
Brown
7
μ
f
F2, 6A F1, 6A
From DC Bus in
Power Structure
X8
X2
4
Fan Frequency Converter
+-
Off
S1-1
Off
S1-2
On
S1-3
Off
S1-4
S1 - Setup Switch
M2
Black
Yellow/Green
Blue
Main Fan Right-Side 230V ac 50 Hz
M
Black 6 Black 5 Black 4 Black 3
Black 2 Black 1
X4 X5
2.2
μ
f 10 M
Ω
2.2
μ
f 10 M
Ω
Brown
7
μ
f
X3
X3
24
Jumper
Figure B.6 Fan Inverter Connections
ahw1019.eps
