3-30 Access Procedures
8. Slide the ASIC board assembly out of its chassis.
9. Remove the plastic board holder.
10. Carefully disconnect the fiber-optic cables from sockets (H8, - H13)
along the back of the ASIC board and carefully set them aside.
11. Disconnect the other cables from sockets on the ASIC board and set
them aside.
Installing the ASIC Circuit
Board
Install the ASIC board in reverse order of removal, while referring to
Torque Specifications on page 3-2
. Reconnect the cables to ASIC board,
while referring to Figure B.3 on page B-4
, Figure B.4 on page B-5 or Figure
B.5 on page B-6.
