- 9 -
ROHO, Inc. recommends that the bottom portion of an AGILITY be
positioned to make contact at the PSIS for optimal pelvic support and
trunk control.
Use the top handle to slightly lift the AGILITY
up and remove it from the wheelchair.
Open the left and right latches by pulling
the latches up.
UNLOCK ( ) the safety locks.
AGILITY REMOVAL
WARNING: DO NOT remove the AGILITY with the individual seated in the wheelchair.
WARNING: If the AGILITY is not positioned to make contact at the PSIS,
pelvic support and trunk control may be reduced.
Posterior, Superior, Illiac Spine (PSIS):
1 2 3
Rotate the back shell to wide or narrow top. Remove the nuts at the end of the width and
height adjustment bolts with the box end
wrench. Detach the triangle brackets from the
back shell.
Note: AGILITY must be removed from the wheelchair before flipping positions.
FLIP BACK SHELL
321
See all ADJUSTMENT and INSTALLATION
sections in this manual.
AGILITY INSTALLATION CONTINUED
PSIS PSIS
